Description
Cells: 144 Cells (6 x 24)
Type: Mono PERC
Dimensions: 2112 x 1052 x 35 mm
Weight: 24.7 kg
Max. load: 5400 Pa
Junction Box: IP67 rated, 3 diodes
Frame: Silver
Connection: MC4
Electrical Characteristics
- Nominal Output (Pmax): 455 W
- Voltage at Pmax (Vmp): 41.82 V
- Current at Pmax (Imp): 10.88 A
- Open Circuit Voltage (Voc): 49.85 V
- Short Circuit Voltage (Isc): 11.41 A
- Max. system voltage: 1000/1500 VDC
- Max. series fuse rating: 20 A
- Module efficiency: 20.5 %
Features:
- High output power
- Less shading effect
- Lower temperature coefficient
- Better mechanical loading tolerance
- Efficiency of 20.2%
- Power output temperature coefficient: 0.35%
- Multi 9 busbar
- Silver frame with white back sheet .
