Description
| MECHANICAL DATA | |
| Cell | Mono |
| Weight | 27.3kg |
| Dimensions | 2278±2mm*1134±2mm*30±1mm |
| Cable Cross Section Size | 4mm²(IEC)，12 AWG(UL) |
| No. of cells | 144(6*24) |
| J-Box | IP68, 3 diodes |
| Connector | QC 4.10-351/ MC4-EVO2A |
| ELECTRICAL DATE(STC) | ||||||
| Rated Maximum Power(Pmax)[W] | 540 | 545 | 550 | 555 | 560 | 565 |
| Power Tolerance | 0~+5W | |||||
| Open Circuit Voltage(Voc) [V] | 49.6 | 49.75 | 49.9 | 50.02 | 50.15 | 50.28 |
| Maximum Power Voltage(Vmp) [V] | 41.64 | 41.8 | 41.96 | 42.11 | 42.27 | 42.42 |
| Short Circuit Current(lsc) [A] | 13.86 | 13.93 | 14 | 14.07 | 14.14 | 14.21 |
| Maximum Power Current(lmp) [A] | 12.97 | 13.04 | 13.11 | 13.18 | 13.25 | 13.32 |
| Module Efficiency[%] | 20.90% | 21.10% | 21.30% | 21.50% | 21.70% | 21.90% |
